Part Number:

JW1-H1950-00-00, JW1-H1950-00, 684-1271-012, 684-1251-012
Replace Part Number: JR3-H1950-00-00, JF2-H1950-00, J38-81950-01, 240-22272

Specification:

Voltage: 12V
Carry Current 150 Amps, Inrush 800 Amps
Terminals: 4
Duty: 100% Continuous
(2) 5/16-24 & (2) Non-Grounded 10-32 Studs
Mounting Type: Flat, L Bracket
Contact: Copper
Sealed Design

Mounting Instructions:

1. Select a desired mounting location
2. Using the contactor as a template, mark the centers of the mounting holes.
3. Using a ¼” drill bit, drill the holes marked in the previous step.
4. Mount the contact using ¼’ bolts and nuts.
5. Wire the relay according to the wiring diagram.
