Hydraulic, RV, Grid Heater & Lawn and Garden Applications
Specification:
12 Volt
Current 150A Max 800A
Duty cycle: 25% sustained (6 min. max on time)
3 Coil terminals: grounded, one (1) 10-32; two (2) contact studs: 5/16-24
Contact material: copper;
Bracket Type: L Bracket curved narrow
Sealed design protects against dust and water jets
